Nokia N80 Quick Start Guide

You can use a compatible miniSD card as extra storage space. Before you
remove the memory card from the slot, press the power key, and select
Remove mem. card. All applications are closed.
Important: Do not remove the memory card in the middle of an
operation when the card is being accessed. Removing the card in the middle
of an operation may damage the memory card as well as the device, and
data stored on the card may be corrupted.
Keys and parts (back)
12
Power key ( )
14
3 megapixel (2048 x 1536) main
camera for high resolution image
capture and video recording
15
LED flash
16
Close-up switch to activate the
close-up mode of the main camera
17
Memory card slot for a miniSD card
19
Capture key for using the main camera
21
Charger connector
20
Pop-Port™ connector for compatible
enhancements
14
2
19
17
21
13
GSM/WCDMA antennas
18
Bluetooth & WLAN antenna
12
20
15
16
13
18
Copyright © 2006 Nokia. All rights reserved.

Nokia N80 Specifications

General

Internal Memory	40 MB
Battery	Removable Li-Ion 820 mAh battery (BL-5B)
Weight	134 g (4.73 oz)
Announced	2005, November
Status	Discontinued
SIM	Mini-SIM
CPU	220 MHz Dual ARM 9
Secondary Camera	CIF videocall camera
Alert types	Vibration; Downloadable polyphonic, monophonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	Wi-Fi 802.11b/g, UPnP technology
GPS	No
Radio	Stereo FM radio
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.0
Stand-by	Up to 192 h
Talk time	Up to 3 h
Colors	Silver, Black
Network	GSM / UMTS
Infrared Port	Yes
Display	TFT, 256K colors
Camera	3.15 MP
Card Slot	miniSD
Operating System	Symbian OS 9.1
Pixel density	259 ppi density
Bluetooth	v1.2
