Nokia N80 Quick Start Guide

(U)SIM card and battery
3
Insert the (U)SIM card and battery
1. With the back of the device facing you,
press the release button, slide the cover,
and lift it up (fig. 3.1).
Always switch the device off, and disconnect
the charger before removing the battery.
2. To release the (U)SIM card holder, slide the
holder, and lift the holder up (fig. 3.2).
3. Insert the (U)SIM card into the holder (fig. 3.3).
Make sure that the bevelled corner on the card is
facing upward from the holder, and that the
contact area on the card is facing the connectors
on the device.
4. Close the holder, and slide it to lock
it into place.
5. Insert the battery (fig. 3.4).
6. Replace the back cover.
Keep all SIM cards out of the reach of small children.
fig. 3.1
fig. 3.2
fig. 3.3
fig. 3.4
Copyright © 2006 Nokia. All rights reserved.

Nokia N80 Specifications

General

Internal Memory	40 MB
Battery	Removable Li-Ion 820 mAh battery (BL-5B)
Weight	134 g (4.73 oz)
Announced	2005, November
Status	Discontinued
SIM	Mini-SIM
CPU	220 MHz Dual ARM 9
Secondary Camera	CIF videocall camera
Alert types	Vibration; Downloadable polyphonic, monophonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	Wi-Fi 802.11b/g, UPnP technology
GPS	No
Radio	Stereo FM radio
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.0
Stand-by	Up to 192 h
Talk time	Up to 3 h
Colors	Silver, Black
Network	GSM / UMTS
Infrared Port	Yes
Display	TFT, 256K colors
Camera	3.15 MP
Card Slot	miniSD
Operating System	Symbian OS 9.1
Pixel density	259 ppi density
Bluetooth	v1.2
