WEP authentication
Enter the wireless equivalent privacy (WEP) key. You can
define more than one WEP key, and you can also select the
default key, if that is required by your WLAN.
WPA authentication
Enter the Wi-Fi protected access (WPA) preshared key. The key
length must be between 8 and 63 characters. Only ASCII
characters are allowed.
WPA with EAP type
To define the extensible authentication protocol (EAP) type,
select from the following:
TLS (transport layer security) authentication — Select the
client certificate used for authentication.
PEAP (protected extensible authentication protocol)
authentication or TTLS (tunnelled transport layer
security) — Select an authentication method used inside
PEAP or TTLS and an optional client certificate.
For MSCHAPv2, define a user name and a password. Select the
Prompt password at every login check box, if you want
your password to be always requested when a connection is
created. For GTC, enter your user name. You are prompted for
a response upon connection creation. The client certificates
are optional. For more information, contact your internet
service provider.
Define advanced settings
Select
> Settings and Internet connections >
Connections. Select the connection and Edit. In the last
dialog, select Advanced.
Wi-Fi proxy settings
Enable proxies
1 Select Use proxy.
2 Enter the IP address of the proxy server, or the host name.
The format of a domain name can be
proxy.company.com.
3 Enter the number of the proxy port.
Bypass proxies
If you have domains for which the use of proxies should be
bypassed, select Do not use proxy for, and enter the domain
names for which the proxy is not needed.
Enable automatic proxies
To obtain the IP addresses automatically from the internet
service provider, select the Automatic configuration check
box, and enter the web address of the server in the Web
address field.
IP address settings
Open the IP Addresses tab.
36 Connect your device
