Service Manual N95 RM-159/RM-245
Copyright © 2007 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page
(58)
13. Push them down evenly.
14. Insert the AV CONNECTOR.
15. …and the DC JACK.
16. Insert the MICROPHONE.
17. Fit the BOTTOM COVER to the CHASSIS now.
18. Place the USB SEAL.
