6212 classic R
M-396
Service Manual Level 1&2
ISSUE 1
Confidential
15
19) Release the NFC ANTENNA MODU
LE with SS-93.
20) Release th
e NFC ANTENNA MODULE on both
sides.
21) Remove the NFC ANTENNA MODULE
.
22) Open the clip of the
LCD SHIELD.
23) Remove the LCD SHIELD ASSY.
24) Remove the EARPIECE.
Copyright @ 2008 NO
KIA. All rights reser
ved
14
16
Table of Contents
Table of Contents
2
Change History
3
Copyright
4
Warnings and Cautions
5
Warnings
5
Cautions
5
ESD Protection
6
Care and Maintenance
7
Battery Information
8
Exploded View
9
Service Devices
10
SW-Update
11
Disassembly Instruction
12
Assembly Hints
18
Solder Components
19
