6212 classic RM-396
Service Manual Level 1&2
ISSUE 1
Confidential
14
13) Unscrew the six T6+ screws in the order
shown and discard them.
14) Release the PWB.
15) Release the NFC ANTENNA MODULE and LCD
SHIELD.
16) Release the LCD.
17) Remove the PWB assembly. 18) Open the connector of the 2PD NFC MODULE.
