6212 classic RM-396
Service Manual Level 1&2
ISSUE 1
Confidential
15
19) Release the NFC ANTENNA MODULE with SS-93. 20) Release the NFC ANTENNA MODULE on both
sides.
21) Remove the NFC ANTENNA MODULE. 22) Open the clip of the LCD SHIELD.
23) Remove the LCD SHIELD ASSY. 24) Remove the EARPIECE.
