6212 classic RM-396
Service Manual Level 1&2
ISSUE 1
Confidential
17
31) Remove the ANTENNA ASSEMBLY. 32) Release the CONN CHR DIA 2.0mm.
End of disassembling
33) Remove the CONN CHR DIA 2.0mm.
Copyright @ 2008 NOKIA. All rights reserved
