Nokia RM-608 Service Manual

Nokia C1-
02
RM-643 / RM-644
Service Manual Level 1&2
13 Confidential | Copyright © 2010 Nokia | All rights reserved Version 1.0
7) Release the A-COVER side from the D-COVER by
sliding the SRT-6 to direction shown. Be careful not
to damage the shown pin.
8) Release the other side of the A-COVER from the D-
COVER by sliding the SRT-6 to direction shown.
9) Remove the A-COVER. 10) Protect the DISPLAY with the protective film.
11) Protect the other side of the A-COVER with the
protective film.
12) Push down to release the KEYMAT.

Nokia RM-608 Specifications

General

Brand	Nokia
Model	RM-608
Category	Cell Phone
Language	English
