BB and RF tuning, EM Calibration
Figure 7 BB and RF tuning option 2
Type Description
Phone specific devices
MJ-345 Module jig
Other devices
CU-4 Control unit
FPS-21 Flash prommer box
PK-1 SW security device
SX-4 Smart card
PC with service software
Measurement equipment
RM-839; RM-840; RM-841
Service Tools and Service Concepts
