Nokia X3 Service Schematics

Customer Care / GTM / Competence Management
Confidential Copyright © 2009 NOKIA Only for training and service purposes
Version: 2.0 | 05.11.2009 | X3 RM-540 | Board version: 2wqa_51a |
Component Finder | Page 7 (7)
Bottom
Top
C2247 M3 C2821 I3 E2102 R8 L7507 G5 R2596 E4
A2700 L7 C2249 N5 C2823 K2 E2104 R7 L7508 G5 R2597 E8
A7500 G5 C2265 M3 C2824 K2 E2105 S8 L 7 5 0 9 G5 R2598 E7
A7501 L4 C2266 M3 C2828 I3 E2106 S8 L7510 G5 R2599 E5
A7502 P9 C2267 L4 C2829 L3 E2120 C6 L7511 G5 R2700 M5
A7503 P7 C2268 M3 C2890 J2 E2121 E4 L7550 E6 R2803 I4
A7504 G3 C2271 N3 C2891 I2 E2122 E6 R2804 I4
C2275 N5 C2901 I5 E2123 C4 M2100 K10 R2880 L4
B2104 D10 C2280 N3 C2902 I5 E2124 R2 R2881 L4
B2200 M3 C2281 N5 C3200 I10 E2 1 2 5 P4 N2002 O7 R2882 L4
B7501
H5 C2282 N4 C3201 H7 E2126 P2 N2100 N5 R2883 L3
C2285 N3 C6001 G3 E2127 R4 N2200 M4 R2884 L4
C2001 O7 C2294 L3 C6002 G3 N2460 K2 R2885 L4
C2002 P6 C2296 N3 C6003 G3 F2001 P 7 N2500 O8 R2886 L4
C2003 P7 C2314 N4 C6004 G3 F2050 O2 N6000 G3 R2887 L3
C2004 P7 C2315 N3 C6005 G4 N6001 G2 R2888 L4
C2050 O3 C2316 M3 C6006 G4 L 2 0 0 1 P7 N7501 H5 R2890 J2
C2051 O3 C2317 M3 C6007 F4 L2050 O2 N7502 F5 R2891 I2
C2081 F 9 C2318 O4 C6008 G3 L2080 L2 R6054 F3
C2082 L2 C2319 N3 C6009 G3 L2100 F10 R2022 O6 R6055 F2
C2083 E9 C2326
N3 C6010 F3 L210 1 P7 R2023 P6 R6059 F2
C2084 F 7 C2347 O5 C6011 G3 L2102 E3 R2024 P7
C2086 E9 C2352 M5 C6012 G4 L2103 E3 R2025 P6 S2501 M2
C2100 P7 C2353 M5 C6013 F4 L2105 P7 R2050 O3 S2502 O2
C2101 F10 C2365 L 4 C6014 F3 L2106 N5 R2081 O7 S2503 D2
C2102 F 3 C2460 K2 C6017 F4 L2110 N5 R2082 F7
C2103 E3 C2480 Q6 C6018 F4 L2120 K5 R2100 L4 V2300 N4
C2104 E10 C2 4 8 1 R7 C6019 G3 L2121 K5 R2103 S8 V2310 N4
C2105 P7 C2482 S7 C6052 G2 L2122 L5 R2106 F3 V2440 J 2
C2108 J 10 C2485 R7 C6053 F2 L2123 L5 R2107 F2 V2441 J2
C21
16 L5 C2499 P8 C6 0 5 4 G2 L2124 O5 R2116 P4 V2500 E5
C2117 K5 C2500 O4 C6055 F2 L2125 O5 R2117 P4 V2501 D7
C2118 L5 C2501 O4 C6056 G2 L21 2 6 J5 R2120 F10 V2502 D5
C2119 L5 C2502 O4 C6057 H2 L2127 J5 R2121 J10 V2503 E7
C2120 P7 C2503 O4 C6063 F2 L2128 L5 R2123 J10 V2505 O3
C2121 P7 C2504 K2 C6064 F2 L2129 L5 R2204 N3 V2549 P5
C2122 L4 C2505 L2 C6070 G4 L2130 E10 R2401 Q5
C2123 N5 C2506 L2 C7501 H5 L2131 E10 R2440 J2 X2003 T5
C2124 N5 C2507 K2 C7502 H6 L2132 N5 R2441 J2 X2080 E7
C2125 N5 C2508 K2 C7503 H6 L2300 O
4 R2443 J2 X2100 S8
C2126 M5 C2509 K2 C7504 H6 L2310 O3 R2444 J2 X2401 R6
C2127 N5 C2510 K2 C7505 H5 L2311 P4 R2460 K2 X2520 P9
C2128 M5 C2518 P8 C7506 H6 L2340 O5 R2501 P8 X2700 K8
C2129 M5 C2519 P7 C7507 H6 L2347 O4 R2502 K2 X2900 D7
C2130 M5 C2595 E4 C7508 H5 L2400 Q7 R2505 O3 X2910 C7
C2132 N5 C2596 E4 C7509 H5 L2500 O4 R2506 O4 X2912 C8
C2140 K5 C2598 P7 C7512 G6 L2501 O4 R2507 P8 X2913 C7
C2141 K5 C2599 O7 C7513 G6 L 2 5 0 6 P8 R2508 P8 X3200 G9
C2150 I 10 C2700 L6 C7514 G6 L2507 P8 R2518 O9 X6001 E2
C2151 I
10 C2800 K5 C 7 5 1 5 G6 L2547 E7 R2519 P9 X6051 E4
C2197 P5 C2801 L4 C7516 G6 L2548 E5 R2537 E7 X6052 H2
C2198 P5 C2804 L3 C7517 G6 L2549 D7 R2538 E5 X6053 N10
C2199 P5 C2805 I5 C7518 G6 L2550 E4 R2539 E5
C2200 N5 C2806 J 2 C7519 G6 L2 5 9 9 P8 R2540 D7 Z2101 N5
C2211 N3 C2807 J 2 C7520 H5 L3200 I 10 R2547 P6 Z2102 N5
C2213 N3 C2808 J 5 C7550 E6 L6002 F4 R2548 P9 Z2500 O8
C2214 N4 C2809 J 2 C7551 G7 L6 0 0 3 F4 R2549 P5 Z2501 P8
C2215 P3 C2810 K5 C7552 G7 L6051 G2 R2550 P8 Z2550 K2
C2222 L4 C2811 L4 C7553 E5 L6052 F2 R255
2 O9 Z6000 F3
C2228 L3 C2812 L3 C7554 E5 L6058 G2 R2553 P9 Z6051 G2
C2229 N4 C2813 J 2 L7500 G5 R2554 P9 Z6053 G2
C2230 N3 C2814 J 2 D2800 K4 L7501 G5 R2555 P9 Z7501 G5
C2231 O5 C2816 I4 D 3 0 0 0 K4 L7502 G6 R2587 E4 Z7502 G5
C2232 L5 C2817 K5 L7503 G5 R2588 E2
C2233 O4 C2818 J2 E1000 S6 L7504 G5 R2589 E2
C2234 O5 C2819 L4 E2100 S8 L7505 G5 R2594 E7
C2245 N4 C2820 L3 E 2 1 0 1 Q8 L7506 G5 R2595 E7
S
V
X
Z
D
E
F
L
M
N
R
A
B
C

Nokia X3 Specifications

General

Display type	TFT
Display diagonal	2.2 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	2048 MB
Internal memory	53 MB
Flash card support	Yes
Maximum memory card size	16 GB
Flash type	LED
Sensor type	CMOS
Photo effects	Negative film, Neutral, Sepia
White balance	Auto, Daylight, Fluorescent, Incandescent
Image formats supported	JPG
Rear camera resolution (numeric)	3.2 MP
Data network	EDGE, GPRS, GSM
SIM card capability	Single SIM
Bundled software	MSN Messenger; Opera mini.
Playback formats	AMR, MIDI, MP3
USB 2.0 ports quantity	1
USB connector type	Micro-USB A
Headphone connectivity	3.5 mm
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Maximum frame rate	15 fps
Video compression formats	3GP, ASF, AVI, MP4
Video capture resolution (max)	176 x 144 pixels
Ringer type	Polyphonic
Audio formats supported	MP3
Polyphonic rings quantity	64
Battery type	BL-4CT
Talk time (2G)	7.5 h
Battery capacity	860 mAh
Standby time (2G)	380 h
Continuous audio playback time	26 h
Volume control	Rotary
Form factor	Slider
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Converter, Countdown timer, Notes, Stopwatch, To-do list
Bluetooth version	2.1+EDR

Weight and Dimensions

Depth	14.1 mm
Width	49.3 mm
Height	96 mm
Weight	103 g
