Nokia X6 Service Manual

Nokia X6
RM-551 / RM-559
Service Manual Level 1&2
2
Confidential
 Copyright © 2009 NOKIA  All rights reserved
Version 1.0 ISSUE 1
Table of contents
1. Change history ............................................................................................................................................................................... 3
2. Copyrig ht .......................................................................................................................................................................................... 4
3. Warnings and cautions ............................................................................................................................................................... 5
3.1 Warnings ................................................................................................................................................................................ 5
3.2 Cautions .................................................................................................................................................................................. 5
4. ESD protection ................................................................................................................................................................................ 6
5. Care and maintenance ................................................................................................................................................................ 7
6. Battery information ..................................................................................................................................................................... 8
7. Exploded view ................................................................................................................................................................................ 9
8. Service devices .............................................................................................................................................................................10
9. SW-update .....................................................................................................................................................................................11
10. Disassembly instructions .....................................................................................................................................................12
11. Assembly hints ........................................................................................................................................................................20
12. Solder components ................................................................................................................................................................21


Nokia X6 Specifications

General

Display diagonal	3.2 \
Display resolution	640 x 360 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Internal memory	32768 MB
Front camera type	Single camera
Rear camera resolution	2592 x 1944 pixels
Video capture resolution (max)	640 x 480 pixels
Personal info management (PIM)	Alarm clock, Calculator, Calendar, events reminder, Notes
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Talk time (2G)	8.5 h
Battery capacity	1320 mAh
Standby time (2G)	401 h
Continuous audio playback time	35 h
Continuous video playback time	3.6 h
Audio formats supported	AMR
Bundled software	Flash Lite 3.0
Form factor	Bar
Product color	Blue, White
2G standards	EDGE, GPRS, HSCSD
Data network	3G, csd, wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	13.8 mm
Width	51 mm
Height	111 mm
Weight	122 g
