Service Manual for L1 and L2
Nokia XL Dual SIM
RM-1030, RM-1042
Key features

Fastlane to Android™ apps

Dual SIM support

5.0" Display

1 GHz Dual-core CPU

5 MP Camera
Version 1.0
CHECK THE REPAIR
POLICY BEFORE
PERFORMING ANY
MECHANICAL REPAIR ON
SERVICE LEVEL 1&2!
Exploded view Disassembly steps
Assembly hints Solder components Service devices
Product controls and interfaces Service concept Phone reset
More More
More More More
More More More
©2014 Nokia | Nokia Internal Use only | All Rights Reserved.

Nokia XL Specifications

General

RAM	768 MB
Internal Storage	4 GB
Expandable Storage	microSD, up to 32 GB
Front Camera	2 MP
Battery	Li-Ion 2000 mAh, removable
Dimensions	141.4 x 77.7 x 10.9 mm (5.57 x 3.06 x 0.43 in)
Weight	190 g (6.70 oz)
SIM	Dual SIM (Micro-SIM, dual stand-by)
Network	GSM / HSPA
Chipset	Qualcomm MSM8225 Snapdragon S4 Play
GPU	Adreno 203
Display Type	IPS LCD
Colors	Bright Green, Orange, Cyan, Yellow, Black, White
WLAN	Wi-Fi 802.11 b/g/n, hotspot
Bluetooth	3.0, A2DP
GPS	Yes, with A-GPS
Radio	FM radio
USB	microUSB 2.0
Display	5.0 inches
Processor	Dual-core 1.0 GHz Cortex-A5
Main Camera	5 MP
Operating System	Android 4.1.2 (Jelly Bean)
