Nokta Simplex LITE User Manual

2
ASSEMBLY
(1) After inserting the washers on the lower shaft, place
the lower shaft in its location on the search coil. Secure
by tightening the screw and nut. Do not overtighten.
(2) To join the middle rod with the upper and lower rods,
open the lever latches and engage the pieces together.
After adjusting the length of the device to your height,
press the latches to secure.
(3) Wind the search coil cable on the shaft without
stretching too much. Then, plug the connector to the
search coil input socket on the system box and secure
by tightening the nut. While tightening, you may hear
clicks indicating that the connector is secured.
(4) If you want to adjust the armrest, first remove the
screws. After sliding the armrest up or down one level,
align the holes and secure by tightening the screws.
You can attach the spare screw to the empty hole if
you do not want to lose it.
(5) Insert the armrest strap as shown in the picture and
adjust it to your arm size and tighten.
1
2
2
3
4
5

Nokta Simplex LITE Specifications

General

Operating Principle	VLF (Very Low Frequency)
Operating Frequency	12 kHz
Weight	1.2 kg (2.6 lbs)
Display	LCD
Pinpoint	Yes
Vibration	Yes
Frequency Shift	Yes
Battery Capacity	2300 mAh
Warranty	2 years
Battery Life	Up to 12 hours
Search Modes	All Metal, Field, Park
Battery	Lithium Polymer
Target ID	0-99
Search Coil	28 cm (11 inch) waterproof DD coil
Length	63 cm - 132 cm (25" - 52")
Ground Balance	Automatic
Audio Output	3.5mm headphone jack
Waterproof	Yes (Search coil: IP68, Control box: IP54)
