nologo START-S4XL User Manual

2

Slow down

Working times learning

Eletrical adjust of the force of the motor

4 functions (apartment block included).

Functions set up throught a dip

Free contact for light indicating the open gate

Radio included which can manage codes rolling.

Small dimensions

Pedestrian door (partial opening) with separate command

Electrical lock and selecting reversing stroke

Dip esclusione di tutti gli ingressi di sicurezza.

Inputs exclusion limit switches with a DIP
The START S4XL control board is designed to move gates. It can be
connected to an oleodinamic motor or electro-mechanical motor with a
single-phase motor, in 230 Vac.
1.2 Field of application
1.1 Description of the product
Making the correct choice of installation is essential to ensuring adequate
safety and good protection against atmospheric agents. Remember that
the control unit contains powered parts and electronic components which
bytheirverynaturearesensitivetoinltrationsandmoisture.Thecontrol
unit is supplied in a container which guarantees an IP55 protection rating
if adequately installed. Install the control unit on a permanent surface that
isperfectlyat,adequatelyprotectedagainstimpactsandatleast40cm
off the ground. The cables must enter the control unit from the bottom
only; we recommend using wire leads and water-tight connections.
Whenusingtubingthatcouldllupwithwaterorifthetubingcomesfrom
anundergroundwell,thewiresmustenterarstshuntingboxplacedat
the same height as the control unit and then, from there, the wires must
be passed into the container holding the control unit, again entering from
the bottom. This prevents any evaporation of the water in the tubing from
forming condensation inside the control unit itself.
2.1 Preliminary checks
Remember that systems for automatic gates and doors must be installed
byhighlyqualiedtechniciansonlyandinfullcompliancewithcurrent
law. Before starting installation, check that the mechanical consistency
and sturdiness of the gate or door, check that the mechanical stops are
suitable to stop the movement of the gate or door even if the electrical
limit switches should fail or during manual operations.
2 Installation
1 Introduction
START-S4XL is the ongoing evolution of the START-S4 electronic control
unit, completely compatible and equipped with a sophisticated electronic
circuit that controls the motive force, detecting any obstacles at any point
in its operation.
The design has adapted the most advanced techniques to guarantee
utmostimmunityvs.noise,maximumoperatingexibilityandtomakea
wide choice of functions available.
Foreword
Thismanualprovidesallthespecicinformationyouneedtofa-
miliarize yourself with and correctly operate your unit. Read it
very carefully when you purchase the instrument and consult it
whenever you have doubts regarding use and before performing
any maintenance operations.
Safety precautions
Usingtheunitimproperlyandperformingrepairsormodications
personally will void the warranty.
Nologo declines any responsibility for damages due to inappro-
priate use of the product and due to any use other than the use
the product was designed for.
Nologo declines any responsibility for consequential damages
except civil liability for the products.
Environmental protection
measures
Information regarding the environment for customers
within the European Union. European Directive EC
2002/96 requires that units bearing this symbol on the
unit and/or on the packaging be disposed of separate-
ly from undifferentiated urban wastes. The symbol in-
dicates that the product must not be disposed of with
the ormal household wastes. The owner is responsible for dis-
posing of this product and other electrical and electronic equip-
mentthroughspecicwastecollectionfacilitiesindicatedbythe
government or local public agencies. Correct disposal and recy-
cling help prevent any potentially negative impact on the environ-
ment and human health. To receive more detailed information
regarding disposal of your unit, we recommend that you contact
the competent public agencies, the waste collection service or
the shop where you purchased the product.
Small legend
LSO - FCA limit switch open
LSC - FCC limit switch closed
START control to drive the gate
PEDESTRIAN in sliding units: control partial opening
Vac alternate current
Vdc direct current
NC normally closed
NA normally open
Isolated contact isolated from power supply
