When the control board is powered, the lights “ l.e.d. are situated in the outputs, they are switched on when on the output
there is a closed contact to the common.
Normally the red l.e.d. in the inputs “Closing limit switches” (FCC) , “opening limit switches”(FCA), STOP, FOTO
are always SWITCHED ON.
Normally the green l.e.d. in the inputs START and PEDONALE (partial opening) are switched OFF
2.5 Description of the connections
4
230 Vac Neutral 1 230 Vac electrical power supplì 50 Hz Neutral
EARTH 2 EARTH
230 Vac Phase 3 230vac electrical power supply 50 Hz Phase
Lamp 4
OutputsforLAMP(ashinglightelectroniccard)or230VACCOURTESYLIGHT
Lamp 5
M 1 Com 6 Output for the connection of motor 1 COMMON POLE M 1
M 1 Opening 7 Output for the connection of motor 1 POLE OPEN MOTOR 1
M 1 Closing 8 Outputs for connections motor no.1 pole CLOSE
M 2 Com 9 Output to connect motor no.2 pole common M2
M 2 Opening 10 Output to connect motor no.2 pole OPEN M2
M 2 Closing 11 Output to connect motor no.2 pole CLOSE
FCC M2 12 Input Closing limit switches motor no.2
FCA M2 13 Input Opening Limit Switches 2
FCC M1 14 Input for Closing limit switches of motor no.1
FCA M1 15 Input for opening limit switches of Motor 1
Photocells A 16 Input Photocell A , working only by closing (see chapter 2.3)
START 17 Input for step-by-step function START
24Vac 18 Output for 24 Vac
24Vac / 12Vac 19 Output for electrical lock 12 Vac 50 Hz 1A
12Vac Lock 20 Output for electrical lock 12 Vac 50 Hz 1A
STOP 21 Pedestrian Stop input
PEDONALE 22 Input for step-by-step function PEDESTRIAN partial opening
Photocells B 23 Input for photocells B working in Closing and in opening (see chap. 2.3)
Common 1 - 24 Common for all inputs: services, Securities, coaxial antenna cable sock.
Antenna + 25 Input for antenna (antenna cable)
light or lamp 26 Contact for Light or LAMP (without electronic card)
light or lamp 27 Contact for Light or LAMP (without electronic card)
PHOTOTEST 28 Output TEST FOR PHOTOCELL 12 Vac
12Vac 29 Output 12Vac
24Vdc + 30 Output 24Vdc +
Comm. 24Vdc - 31 Output 24Vdc - Common for inputs: services and safety
