se c t i o n 11 —wA t e r di s p e n s e r
The water dispenser is an optional system
installed at the factory. The main components
are the divider mounted water dispenser
(Figure 11-1), the reservoir (Figure 11-2), and
the water valve (Figure 11-3).
Figure. 11-1. —Water dispenser-external view.
Figure. 11-2. —Reservoir in cabinet recess and cover.
Figure. 11-3. —12 volt DC solenoid operated water
valve.
Water valve - BLUE solenoid coil
Cover -
attached with hook and loop tape
Reservoir -27 . oz. capacity
