Installation and Owner’s Guide 9
Wiring Diagram and Pictorial
Replacement Parts
You may purchase replacement parts through your local RV
dealer or Norcold authorized Service Center.
The parts of the wiring pictorial are (See Art01994:
94....................................................................................DC heater
92....................................................................................AC heater
230.........................................................................Chassis ground
222..........................................................Thermocouple interrupter
220................................................................................3 Amp fuse
223..............................................................................20 Amp fuse
219...........................................................................Terminal block
96..................................................................................Thermostat
98..................................................................................Thermostat
207 ...................................................................................... Switch
108....................................................................................120 VAC
99..................................................................................... 12 VDC+
224..............................................................................12VDC Com
221...........................................................................Thermocouple
237................................................................................1 Amp fuse
89a.........................................................................Spark electrode
91................................................................................ Safety valve
97..............................................................................................Fan
238....................................................................................Relighter
217......................................................................... Flame indicator
* .........................................Fan operation-propane gas mode only
** .............................................................. Fan operation-all modes
Safety Awareness
Safety Instructions
Read this manual carefully and understand the contents before
you install the refrigerator.
Be aware of possible safety hazards when you see the safety
alert symbol on the refrigerator and in this manual. A signal word
follows the safety alert symbol and identies the danger of the
hazard. Carefully read the descriptions of these signal words to
fully know their meanings. They are for your safety.
WARNING: This signal word identies a hazard, which
if ignored, can cause dangerous personal injury, death, or
much property damage.
CAUTION: This signal word identies a hazard, which if
ignored, can cause small personal injury or much property
damage.
WARNING:
- This refrigerator is not approved for use as a free standing
refrigerator. It is equipped for the use of propane gas only
and can not be changed to use any other fuels (natural
gas, butane, etc.).
- Incorrect installation, adjustment, changes to, or
maintenance of this refrigerator can cause personal injury,
property damage, or both.
- Obey the instructions in this manual to install the intake
and exhaust vents.
- Do not install the refrigerator directly on carpet. Put the
refrigerator on a metal or wood panel that extends the full
width and depth of the refrigerator enclosure.
- Do not allow anythaing to touch the refrigerator cooling
system.
- Propane gas can ignite and cause an explosion that can
result in property damage, personal injury, or death. Do
not smoke or create sparks. Do not use an open ame
to examine the propane gas supply line for leaks. Always
use two wrenches to tighten or loosen the propane gas
supply line connections.
- Make sure the electrical installation obeys all applicable
codes. See the “Certication and Code Requirements”
section of this manual.
- Do not bypass or change the refrigerator’s electrical
components or features.
- Do not spray liquids near electrical outlets, connections, or
the refrigerator components. Many liquids are electrically
conductive and can cause a shock hazard, electrical shorts
and in some cases, re.
Installation Manual
!
!
!
