Norcold 443 - Page 4

Component Location and
Identification (Single Door
Models)
A. Illuminated Ignition Switch
B. Flame On Indicator Lamp
C. Thermostat Control Knob
D. Combination Control Knob
1. Gas On/Electric Interlock
2. Push-In Safety Valve
E. AC/DC Mode Selector Switch
(3-Way models only)
F. Serial Identification Plate
Component Location and
Identification (Two Door
Models)
A. Illuminated Ignition Switch
B. Flame On Indicator Lamp
C. Thermostat Control Knob
D. Combination Control Knob
1. Gas On/Electric Interlock
2. Push-in Safety Valve
E. AC/DC Mode Selector Switch
(3-Way models only)
F. Serial Identification Plate
G. Three Position Switch (See
page 3-6)
1. NORMAL
2. STORAGE
3. HIGH HUMIDITY
H. Interior Light Switch
A B C D E
F
G H
Figure 3.3 Controls Location, Two Door Model
A B C D E
F
Figure 3.2 Controls Location, Single Door Model
A008
3-4
