6000 SERIES PARTS LIST - PAGE 5
CABINET ASSEMBLY - FRONT VIEW - 605 SERIES
NO. PART # DESCRIPTION 605
1 61582030 HOLE PLUG-BLACK/HINGE HOLES X
2 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR X
3 619041 SPRING HOLDER ASSY-RH/EVAP DOOR/SILVER SPRING X
4 61571522 CABLE-GRAY/ 80"/PC BOARD TO POWER SUPPLY BOARD X
5 61660937 EYEBROW ASSY-EG2 EG2
5 61661037 EYEBROW ASSY-EG3 EG3
6 61693822 THERMISTER-66" X
7 61689122 CLIP-THERMISTER MOUNTING/FIN X
8 61580830 HINGE BRACKET-RH TOP/LH BTM/BLACK X
9 61578130 HINGE PIN-BLACK/MALE X
10 61630422 ICE CUBE TRAY-PLASTIC X
11 61578522 DOOR LATCH X
12 61619930 DRIP TRAY-INSIDE X
13 618651 SHELF-WIRE/CUT OUT (TOP SHELF/LATEST VERSION) X
618059 SHELF-WIRE/SHORT (TOP SHELF/EARLIER VERSION) X
61718222 SHELF-WIRE/SHORT (USE 618059)(TOP SHELF/EARLIER VERSION) X
14 618649 SHELF-WIRE/MIDDLE (BOTTOM SHELF/LATEST VERSION) X
618055 SHELF-WIRE/CUT OUT (EARLIER VERSION) X
61646722 SHELF-WIRE/WITH CUT OUT (USE 618055) (BOTTOM SHELF/EARLIER VERSION) X
NS 61622722 RETAINER-WIRE SHELF (NOT SHOWN) X
15 61580322 RETAINER-GLASS SHELF X
16 61564122 CRISPER COVER-GLASS SHELF X
17 61571325 CRISPER-WHITE/HALF CRISPER (EARLER VERSION) X
618571 CRISPER-WHITE/FULL (LATEST VERSION) X
18 61580930 HINGE BRACKET-LH TOP/RH BTM/BLACK X
19 61622130 FRONT COVER-BLACK/REPLACEABLE BOTTOM TRIM X
20 619042 SPRING HOLDER ASSY-LH/EVAP DOOR/YELLOW SPRING X
21 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATOR DOOR X
22 61620738 EVAPORATOR DOOR ASSY-WHITE/WITHOUT DECAL X
NS 61618730 DOOR GASKET-EVAPORATOR/GRAY (NOT SHOWN) X
NS 61579730 CAP-SNAP ON/BLACK/INSTALLATION HOLES (NOT SHOWN) X
NS 61580630 HINGE PIN-BLACK/TOP/BOTTOM HINGE/FEMALE (NOT SHOWN) X
