6000 SERIES PARTS LIST - PAGE 9
CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - 6000 SERIES
NO. PART # DESCRIPTION 605 606 608 616 618
1 61687140 NSC SYSTEM PACK-COOLING UNIT/NA6 X
632311 NSC SYSTEM PACK-COOLING UNIT/NA8 X X
632318 NSC SYSTEM PACK-COOLING UNIT/NA10 X X
NS 61679337 BAFFLE DIFFUSER/WIRE ASSY (NOT SHOWN)(USE 61632010/61679022) X
NS 61679237 BAFFLE DIFFUSER/WIRE ASSY (NOT SHOWN)(USE 618111) XXXX
261536522 CLAMP-NYLON CABLE 1/2" XXXXX
3 61509522 DRAIN HOSE (USE 622390) X X
61591422 DRAIN HOSE-23" (USE 622390) X X
NS61505122 HOSE CLAMP (NOT SHOWN) XXXX
461710922 DRIP CUP-REAR/METAL (USE 622546) XXXX
5 61712637 COVER ASSY-BURNER BOX XXXXX
6 61695322 BASE-BURNER BOX XXXXX
7 61562522 HEATER-AC X
621702 HEATER-AC (COOLING UNIT SERIAL# 11231023 & BELOW) X X
HEATER-AC (COOLING UNIT SERIAL# 11232007 & BELOW) X X
630811 HEATER-AC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) X X
HEATER-AC/BACKER (COOLING UNIT SERIAL# 11232008 & ABOVE) X X
8 61562622 HEATER-DC EG3
626832 HEATER-DC (COOLING UNIT SERIAL# 11231023 & BELOW) EG3 EG3
HEATER-DC (COOLING UNIT SERIAL# 11232007 & BELOW) EG3 EG3
630812 HEATER-DC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) EG3 EG3
HEATER-DC/BACKER (COOLING UNIT SERIAL# 11232008 & ABOVE) EG3 EG3
961695022 CAP-HEAT DEFLECTOR XXXXX
10 61686823 FINS XXX
61449423-AFINS-ARCTEK XXXX
1161571522 CABLE-GRAY/ 80"/PC BOARD TO POWER SUPPLY BOARD XXXXX
1261693822 THERMISTER-66" XXXXX
1361718722 HUMIDITY SWITCH HARNESS ASSY XXXX
