DE251E/EV251E PARTS LIST - PAGE 6
DOOR ASSEMBLY - DE251E/EV251E
NO. PART # DESCRIPTION DE251E EV251E
200 160017600 DOOR ASSY-BLACK (USE 160031620) X X
160031620 DOOR KIT ASSY-GRAY X X
160017640 DOOR ASSY-WHITE (USE 160031620) X X
160031630 DOOR KIT ASSY-WHITE (USE 160031620) X X
201 302308310 DOOR PANEL-BLACK XX
302303260 DOOR PANEL-WHITE XX
202 160907510 DOOR FRAME ASSY-BLACK/3 SIDES (USE 160031620) X X
160907530 DOOR FRAME ASSY-WHITE/3 SIDES (USE 160031620) X X
203 404004700 HINGE BUSHING-POINTED X X
204 439003610 CUSHION-DOOR SHELF X X
205 433100510 DOOR LINER XX
206 242504000 BAR-BOTTLE HOLDER X X
207 414801200 DOOR GASKET XX
208 427600510 DOOR FRAME-BOTTOM/BLACK X X
427600530 DOOR FRAME-BOTTOM/WHITE X X
209 404001000 HINGE BUSHING XX
210 80830441210 SCREW-TRUSS TAPPING/M4x12 X X
211 412006610 CUSHION-DOOR ASSY/VERTICAL X X
212 545008203 MARK-NORCOLD/BLACK X X
