Norcold DE-461 - Door - Upper (Freezer) - De461;De461 T;Ev461

DE461/EV461 PARTS LIST - PAGE 2
DOOR - UPPER (FREEZER) - DE461/DE461T/EV461
NO. PART # DESCRIPTION DE461 EV461
1 61567830 DOOR GASKET-UPPER/GRAY X X
2 61631330 HINGE PLATE-BLACK/RH TOP/LH BOTTOM/PLASTIC X X
3 61689938 DOOR LINER ASSY-FOAMED/UPPER/BLACK/WHITE X X
NS 61592930 PANEL HOLDER-BLACK/UPPER DOOR (NOT SHOWN) X X
4 61743638 DOOR HANDLE ASSY-UPPER/BLACK X X
5 61593830 END CAP-BLACK/STOP CATCH X X
6 61743622 DOOR HANDLE WITH DECAL-UPPER X X
7 61593730 END CAP-BLACK/SPRING CATCH X X
NS 61558822 SPRING-DOOR HANDLE (NOT SHOWN) X X
8 61631430 HINGE PLATE-BLACK/LH TOP/RH BOTTOM/PLASTIC X X
9 61580525 JUICE RACK-WHITE XX
10 61564025 BIN-DOOR SHELF/WHITE XX
