DE461/EV461 PARTS LIST - PAGE 5
CABINET ASSEMBLY - FRONT VIEW - DE461/DE461T/EV461
NO. PART # DESCRIPTION DE461 EV461
1 61578522 DOOR LATCH XX
2 61630422 ICE CUBE TRAY-PLASTIC (2 PER REFRIGERATOR) 2 2
3 61580830 HINGE BRACKET-RH TOP/LH BTM/BLACK X X
4 61578130 HINGE PIN-BLACK/MALE XX
NS 61580630 HINGE PIN-BLACK/TOP/BOTTOM HINGE/FEMALE (NOT SHOWN) X X
5 61566730 HINGE PIN SHAFT-BLACK/AT CENTER HINGE X X
6 61580722 HINGE BUSHING-AT CENTER HINGE X X
7 61566530 HINGE BRACKET-BLACK/CENTER HINGE X X
8 618056 SHELF-WIRE/WHITE/FLIPPER X X
NS 618065 CAP-CLEAR/FOR FLIPPER SHELF (NOT SHOWN) X X
9 618052 SHELF-WIRE/MIDDLE XX
10 618055 SHELF-WIRE/CUT OUT XX
NS 61580222 RETAINER-WIRE SHELF (NOT SHOWN) X X
11 61564122 CRISPER COVER-GLASS SHELF X X
NS 61580322 RETAINER-GLASS SHELF (NOT SHOWN) X X
12 61571325 CRISPER-WHITE XX
13 61580930 HINGE BRACKET-LH TOP/RH BTM/BLACK X X
14 61622130 FRONT COVER-BLACK/REPLACEABLE BOTTOM TRIM X X
15 620377 THERMOSTAT-160114410 XX
160206700 KNOB-THERMOSTAT/61729422 X X
16 620502 COVER PLATE-THERMOSTAT X X
17 61686722 COVER PLATE-FRONT/BLACK X X
18 61772122 BOTTOM PAN-SUPPORT ASSY X X
19 61691310 DRIP TRAY XX
NS 61706522 HOLE PLUG-FOR DRIP TRAY (NOT SHOWN) X X
NS 61693622 RETAINING CLIP-DRIP TRAY (NOT SHOWN) X X
NS 61579730 CAP-SNAP ON/BLACK/INSTALLATION HOLES (NOT SHOWN) X X
