DE461/EV461 PARTS LIST - PAGE 6
CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DE461/DE461T/EV461
NO. PART # DESCRIPTION DE461 EV461
1 620541 POWER SUPPLY-DE461/160115500 X
620544 POWER SUPPLY-EV461/160115510 X
NS 160928900 FAN ONLY-50 CYCLE/40 WATT (NOT SHOWN) X X
NS 160929310 FAN ONLY-50 CYCLE/LARGE (NOT SHOWN) X X
2 61691522 PANEL COVER-UPPER BACK X X
3 61691938 FOAM PLUG ASSY XX
4 617844 COOLING UNIT-DE461/EV561/161008410 X X
161008430 COOLING UNIT-DE461T T
NS 620648 THERMISTER-DE461/EV461/605505440 (NOT SHOWN) X X
NS 190264730 CORD ASSY-COMPRESSOR CORD (NOT SHOWN) X X
NS 191238400 CORD ASSY-THERMOSTAT TO POWER SUPPLY/600 MM (NOT SHOWN) X X
NS 192116605 CORD WITH TERMINAL-GROUND CORD (NOT SHOWN) X X
NS 601058020 COUPLER ASSY-FANS TO POWER SUPPLY (NOT SHOWN) X X
