Norcold N1095 - Replacement Parts; Wiring Diagram and Pictorial; Ice Maker Wiring Pictorial and Diagram; N109 XIMXX Models)

Owner’s Manual 14
Ice Maker Wiring Pictorial and Diagram
(N109XIM and N109XIMXX models)
The parts of the ice maker wiring pictorial and diagram are (See
Art01016):
120V AC Hot ................................................................................ 1
PC Board .................................................................................... 2
Ground screw ............................................................................. 3
Hot / smooth ............................................................................... 4
Neutral / Ribbed ......................................................................... 5
Solenoid Water Valve.................................................................. 6
Thermal Fuse ............................................................................. 7
Ice maker .................................................................................... 8
Mold Heater ................................................................................ 9
Thermostat ............................................................................... 10
Shut Off Switch ..........................................................................11
Fill Switch.................................................................................. 12
Holding Switch ......................................................................... 13
Motor ......................................................................................... 14
120V AC Neutral ....................................................................... 15
Replacement Parts
You may purchase replacement parts through your local RV
dealer or authorized Norcold Service Center.
Wiring Diagram and Pictorial
The parts in the wiring pictorial are (See Art01771):
The parts in the wiring diagram are (See Art01772):
A.................................................................................... AC heater
B............................................................................................ Light
C ..................................................................................Thermister
D ....................................................................................Gas valve
E.......................................................................................... Igniter
F ..............................................................................Divider heater
G ...................................................Temperature switch (optional)
H ...................................................Temperature switch (optional)
I ...............................................................................Fan (optional)
J ........................................Ice maker water line heater (optional)
K................................................................... DC heater (optional)
L .......................................................................... Chassis ground
M ................................................................... DC board (optional)
N ................................................................................ Door switch
1 ........................................................................ Switched 12 VDC
2 ......................................................... Fused continuous 12 VDC
3 ........................................................................ Communications
4 ............................................................................Display ground
5 ...........................................................................Auxiliary ground
6 ........................................................................ Auxiliary +12 VDC
7 ..........................................................................Divider +12 VDC
8 ..................................................................... Gas valve +12 VDC
F1 .......................................................................... 5 Amp fuse DC
F2 ........................................................................... 8 Amp fuse AC
F3 ........................................................................ 30 Amp fuse DC
