Norcold N64X Installation Manual

Installation Manual 5
- Make sure there is less than 1/4 inch clearance [15]
between the bafe and the top of the refrigerator.
- Make sure the bafe is the full width of the inside of
the enclosure.
- If the design of the vehicle does not allow you to install the
roof exhaust vent directly above the condenser [11] of the
refrigerator (See Art01599):
- Align the roof exhaust vent [12] above the condenser
[11] of the refrigerator and move it inboard as necessary.
- Install two bafes [13] to prevent stagnant hot air in the
area [14] above the refrigerator.
- Make sure the bafes are the full width of the inside
of the enclosure.
- Make sure that the bafes are no more than 45°
from vertical [20].
- Put one bafe between the top rear edge of the
refrigerator and the inside edge of the upper
exhaust vent opening.
- Put the other bafe between the outside edge of the
upper exhaust vent opening and the side wall of the
vehicle.
- If the depth of the enclosure is 24 inches or more and is less
than 25 inches, no bafes are necessary at the rear of the
enclosure.
- If the depth of the enclosure is 25 inches or more and is
less than 26 inches, add two bafes [16] to the rear of the
enclosure (See Art01598 and Art01599).
- Put one bafe 18 inches to 18 1/2 inches above the
bottom of the enclosure [17] (4 1/4 inches to 4 3/4
inches above the top of the lower intake vent opening
REF) [18] .
- Put the other bafe at the lowest edge of the condenser
[11] of the refrigerator.
- Make sure that the bafes are 1 inch or less [19]
from the coils [10] and condenser of the refrigerator.
- Make sure that the bafes are the full width of the
inside of the enclosure.
- If the depth of the enclosure is more than 26 inches, install
a wood or an aluminum or galvanized sheet solid box
bafe [21] in the rear of the enclosure (See Art01617 and
Art01618).
- Make sure that the bottom of the solid box bafe is
18 inches to 18 1/2 inches above the bottom of the
enclosure [17] (4 1/4 inches to 4 3/4 inches above the
top of the lower intake vent opening REF) [18].
- Make sure that the back of the solid box bafe is
perpendicular to the bottom of the enclosure.
- Make sure that the back of the solid box bafe is either
against the top of the enclosure or against the angled
bafe [13] (depending on the vehicle design).
- Make sure that the solid box bafe is one inch or
less [19] from the coils [10] and condenser of the
refrigerator.
- Make sure that the solid box bafe is the full width
of the inside of the enclosure.
- If the design of the vehicle does not allow you to install a roof
exhaust vent, install an upper side-wall exhaust vent.
NOTE: The refrigerator is 23.7 in. min. to 24.0 in. max. from
the rear of the breaker to the rear of the condenser
[22].
N62X, N62XXX, N64X, N64XXX, N64XIM, and
N64XIMXX models are 47.1 in. min. to 47.4 in. max.
from the bottom of the refrigerator to the bottom of the
refrigerator condenser [23].
N82X, N82XXX, N84X, N84XXX, N84XIM, and
N84XIMXX models are 54.1 in. min. to 54.4 in. max.
from the bottom of the refrigerator to the bottom of the
refrigerator condenser [23] (See Art01601).
CAUTION: Only use an upper side-wall exhaust
vent on refrigerator models that are equipped with a
fan. If you use an upper side-wall exhaust vent on a
refrigerator model that is not equipped with a fan, the
refrigerator cooling performance will be poor.
- Make sure the refrigerator model is equipped with a fan.
- Install the upper side-wall exhaust vent [24] (See
Art01592 and Art01593).
- For N62X, N62XXX, N64X, N64XXX, N64XIM, and
N64XIMXX models, make sure the distance [25]
from the bottom of the enclosure to the top of the
rough opening for the upper exhaust vent is at least
55 inches.
!
