Polar Series N10LX, NA10LX
N10LX, NA10LX Models - Electronic
■ Capacitive Touch - ON/OFF, Mode, and Temperature Set
■ Backlit LCD Display with Icon, Numerical, and Text Indicators
■ Self-Diagnostic with Fault Codes
■ 2-Way Automatic or Manual Operation (Standard)
■ Nine (9) Separate Temperature Settings (With Backup Operating System Mode)
■ Sleep Mode
■ Twelve (12) Individual Diagnostic Screens
Rough Opening Dimensions (H x W x D)
N10LX, NA10LX Models ------------------------------------------59.88 - 60.01 in. x 23.50 - 23.63 x 24.00 - 24.13 in.
DC (Direct Current) Specifi cations
Electronic Controls DC Input Voltage Requirement ----------------------------------------------10.5 VDC to 16.0 VDC
DC Fuse Requirements
Main Control Board (Power Board) F1 - Control Circuit----5 Amp, 32 V, MINI ® Blade, Automotive Style Fuse
Main Control Board (Power Board) F2 - Auxiliary Circuit 7.5 Amp, 32 V, MINI ® Blade, Automotive Style Fuse
DC Resistance / Amperage Ratings
Divider Heater -----------------------------------------------------------------43 Ω to 50 Ω, 240 mA to 279 mA @ 12 VDC
Cold Weather Heater (optional) --------------- ------------------------------- 6.7 Ω to 7.8 Ω, 1.5 A to 1.8 A @ 12 VDC
Ice Maker Water Line Heater (IM models only) --------------------------- 6.7 Ω to 7.8 Ω, 1.5 A to 1.8 A @ 12 VDC
External Cooling Fan ------------------------------------------------------------------------------------------430 mA @ 12 VDC
Interior Light -----------------------------------------------------------------------------------------------------------------
180 mA
AC (Alternating Current) Specifi cations
Electronic Controls AC Input Voltage Requirement ------------------------------------------------ 108 VAC to 132 VAC
AC Fuse Requirements
Power Board F3 ---------------------------------------------------------- 8 Amp, 250 V Glass FST 5 x 20 mm GMA Type
AC Current Draw
AC Heater ----------------------------- 1 each, 300 W @120 VAC, (45.7 Ω to 50.5 Ω), 2.38 A to 2.63 A @ 120 VAC
Ice Maker Water Valve (IM models only) -------------------------------------------------------------------10 W @ 120 VAC
Propane gas
Operating Pressure ------------------------------------------------------------------------------10.5 - 11.5 Inch w.c.
Burner Rating (Heat output) --------------------------------------------------------------------------1750 Btu/h @ 11 in. w.c.
Burner Orifi ce Size ---------------------------------------------------------------------------------------LP18 (not replaceable)
Gas Ignition ---------------------------------------------------------------------------------------Electronic with Flame Sensing
Electrode Tip-to-Burner Gap -------------------------------------------------------------------------------------1/8 to 3/16 inch
Off-level operating limits
Side-to-Side -------------------------------------------------------------------------------------------------- 3 Degrees-Maximum
Front-to-Back ------------------------------------------------------------------------------------------------ 6 Degrees-Maximum
SPECIFICATIONS
