Owner’s Manual 5
Door bin slide:
Each door bin includes an adjustable door bin slide [53] to prevent the bin contents from moving or overturning during transit (See Art
02632).
Push each door bin slide against the bin contents. To remove each door bin slide, rotate it
out of the bin. Rotate each bin slide into the bin to install.
Adjustable shelves:
The shelves in the freezer and the fresh food compartment are made so you can remove
them or move them.
To move or remove the wire shelf of the freezer:
- Locate the plastic clip that is around the wire shelf.
- Remove and save the screw that attaches the plastic clip to the inside of the refrigerator
cabinet.
- Lift the left side of the shelf upward to remove the shelf.
- Push the wire shelf fully into the slot that you wish.
- Put the plastic clip back in the original position on the wire shelf.
- Attach the plastic clip with the screw.
To remove or move the large shelves of the fresh food compartment:
- Locate the plastic clip [202] that is around each wire shelf [203] (See Art
01692).
- Remove and save the screw [41] that attaches the plastic clip to the inside of
the refrigerator cabinet.
- Pull the shelf slightly forward to disengage the left side of the shelf from the
slot [157] of the refrigerator cabinet and lift the left side of the shelf to remove
the shelf.
- Put each wire shelf into the slot that you wish.
- Put the plastic clip back in the original position on each wire shelf.
- Attach the plastic clip with the screw.
To remove the small top shelf of the fresh food compartment:
- Locate the plastic clip [202] that is around the wire shelf [203] (See Art
01692).
- Remove and save the screw [41] that attaches the plastic clip to the inside of
the refrigerator cabinet.
- Pull the shelf forward out of the slot [157].
- Put the wire shelf into the slot.
- Put the plastic clip back in the original position on the wire shelf.
- Attach the plastic clip with the screw.
Art 01692
202
41
157
203
53
52
Art 02632
