Nordic ND6

Installation and Operating Instructions
NORDIC DELUXE 6
1712-60-0204
NORDIC DELUXE 8
1712-80-0204
6 28 sq. ft. 74" 175 96" 310 1 120/240 25
2 #10AWG+N+GR 4 #14AWG+GR
8 40 sq. ft. 74" 250 96" 425 1 120/240 33.3
2 #8AWG+N+GR 4 #14AWG+GR
SEE
NOTE
1
BELOW
!
DIAGRAM 2
Page 2
OBSERVING MINIMUM DISTANCES IS REQUIRED TO REDUCE FIRE HAZARD
Recheck your distances from the
heater to combustible materials to be
sure you have the proper minimum
distances.
MOUNTING BRACKET LOCATION AND TO MINIMUM DISTANCE TO COMBUSTIBLE MATERIAL
DIAGRAM 1
NORDIC DELUXE 6
NORDIC DELUXE 8
4.0" 4 5/8" 5.0" 10 3/4" 23"
5.0" 5 5/8" 6.0" 11 1/2" 23"
"A"
DISTANCE
HEATER
"B"
DISTANCE
"C"
DISTANCE
"D"
DISTANCE
"K"
DISTANCE
MINIMUM
