Do not locate benches over heater. Mini-
mum clearance of ceiling above heater 44".
Minimum clearance from heater to wooden
surfaces (benches, side walls, heater
fence, etc.) 2 inches. Mounting brackets
supplied. Provides proper clearance from
wall behind heater.
Use only copper wire of the size and type
indicated in the Heater Specification Chart
and the temperature rating on the heater
junction box.
All heaters and controls must be grounded
per NEC to prevent electrical shock in case
of unit failure.
Electrical outlets or receptacle must not be
installed in a sauna room.
A guardrail or fence is required around the
heater to prevent burns from accidental
contact.
WARNING
Installation and Operating Instructions
Section 7: Operation
The heater is intended for use with a SC-9, SC-60, or
SC-CLUB Control Panel only. Use with any other control
voids the warranty and UL listing. For health and fire safety,
never attempt to alter or bypass the timer or thermostat. If
the sauna is to be used without an automatic timer provided,
(Model SC-CLUB Control Panel) an attendant must be pres-
ent at all times.
MODEL SC-9 CONTROL PANEL, UL number 19-8-
1517 (9 Hour Delay 1 Hour Operation Option) This control is
equipped with a 60 minute timer with a 9 hour delay, an
electronic thermostat, a light switch, and a pilot lamp that
indicates when the heater is on.
SETTING THE TEMPERATURE: The temperature can be
adjusted by turning the thermostat knob. To raise the
temperature, turn the knob clockwise; to lower the tempera-
ture, turn the knob counter-clockwise.
SETTING THE TIME: If you want the heater to begin heating
immediately, turn the dial clockwise past the first marked
section labeled “off to 1” (See Diagram 4), then turn the dial
back (counter-clockwise) until you feel it “click”, near the on
position, into the one hour operation zone.
The heater has a “9 plus 1” timer, which means you can set
the
heater to begin heating after a delay of up to 9 hours. If
you set the timer dial in the “1 to 9” zone, the heater will auto-
matically turn on after the selected delay time has elapsed.
LIGHT SWITCH: Use the light switch to turn on the sauna
room light on and off.
MODEL SC-60 CONTROL PANEL, UL Number
19-8-1817 (60 minute timer) This control panel has a 60
minute timer, an electronic thermostat, a light switch, and a
pilot lamp that indicates when the heater is operable.
SETTING THE TEMPERATURE: The temperature can be
adjusted by turning the thermostat knob. To raise the
temperature, turn the knob clockwise; to lower the tempera-
ture, turn the knob counter-clockwise.
SETTING THE TIME: Use the timer to turn the heater on. To
start the heater, turn the timer knob clockwise to the desired
time setting. Maximum operating time is one hour.
LIGHT SWITCH: Use the light switch to turn on the sauna
room light on and off.
Page 5
