14
12. Identify the left handrail assembly (P). Attach
the left handrail assembly to the left side
of the console base assembly (N) with two
3/8" x 2 1/4" Screws (1); do not fully tighten
the Screws yet.
12
1
N
P
13. Attach the right handrail assembly (Q) to the
right side of the console base assembly (N)
with two 3/8" x 2 1/4" Screws (1); do not fully
tighten the Screws yet.
1
13
N
Q
