15
Heating Element
Assembly
Motor
Mount Kit
Blower
Motor
Blower
Wheel
Blower
Housing
Transformer
Control
Board
Coil Assembly
Outlet Heater Box
Lower Front
Bracket
Blower
Door
Motor Control
Board
Rear
Bracket
Front Joining
Bracket
Figure 8. MB7 Series Component Locations
