Nordyne MB7BM Series User Manual

24
WIRING DIAGRAM
(Replaces 7110750)
Air Handler
Legend
Field Wiring
Factory Wiring:
Low Voltage High Voltage
¢711075"¤
1009
711075A
CAP.
1 3 5 2
1 2
4 6
HEATER PLUG
RELAY
RELAY
Y
L2 L1
EAC
COOL
HEAT
W
G
R
C
R C L2 L1
-
7 6 5 4 3 2 1
1=COM 2=CAP. 3=CAP. 4=HI 5=MED 6=LOW
240
24 V
208 COM
TRANSFORMER
R
C
LOCATION OF “T” CONNECTOR
MOTOR
3-SPEED
4-PIN PLUG (18)
CUT WIRES TO REMOVE PLUG HOUSING WHEN HEATER KIT NOT INSTALLED
BLACK
RED
WHITE
BROWN
BROWN
BLACK
WHITE
RED
GRAY
YELLOW
WHITE
GREEN
GRAY
RED
NOTES: 1. The blower motor speed tap connection may not be as shown. See the Installation Instructions. 2. Disconnect all power before servicing. 3. Transformer may have a dual voltage primary tap. Match the tap position with the supply voltage used. 4. If the internal wiring is replaced, use only 105°C copper wire of the same gauge.
RED
BLACK
BLW DTC
R
BLACK
IF BOARD EQUIPPED WITH BLWDTC TERMINAL
Figure 14. Wiring Diagram for MB7BM Series Air Handler
