Noritz N-0841MC Series User Manual

9
Indoor/Outdoor Wall Mounted, Power Vented Model
* The above illustration shows an example of installation.
The exact installation configuration may be slightly different.
Main Unit
Flue Collar
Front Cover
Air Inlet
Water Supply Valve
Gas Supply Valve
Water Drain Valve (with Water Filter)
(Inside Water Inlet) ( p.22)
Pressure Relief Valve
General Parts-1
Drain Pipe
Discharges the
condensate.
NCC199-DV
Indoor Wall Mounted,
Power Vent/Sealed Model
Flue Collar
Intake pipe
(Ex. NCC199-SV)

Noritz N-0841MC Series Specifications

General

Brand	Noritz
Model	N-0841MC Series
Category	Water Heater
Language	English
