ODU IP Address Page
192.168.077.030
^
The ODU IP Address Page allows the user configure the ODU’s IP address to match the IP
address on the ODU. The Next and Previous buttons select which digit to change. The Up and
Down buttons change the value of the selected digit by one. The maximum value for each section
is 255.
Pressing Enter saves the new IP address and returns the user to the Network Settings page.
Pressing Back takes the user to the Network Settings page without saving any values.
IDU IP Address Page
192.168.077.031
^
The IDU IP Address Page allows the user to change the IDU’s IP address. The Next and
Previous buttons select which digit to change. The Up and Down buttons change the value of
the selected digit by 1. The maximum value for each section is 255.
Pressing Enter saves the new IP address and returns the user to the Network Settings page.
Pressing Back takes the user to the Network Settings page without saving any values.
Subnet Page
255.255.255.000
^
The Subnet Page allows the user to change the subnet that the IDU-ODU network operates on.
The Next and Previous buttons select which digit to change. The Up and Down buttons change
the value of the selected digit by 1. The maximum value for each section is 255.
Pressing Enter saves the new IP address and returns the user to the Network Settings page.
Pressing Back takes the user to the Network Settings page without saving any values.
