Nortec NHPC User Manual

Spare Parts| 88
Table 11: NHTC/PC 005-030 Electrical Parts List
MODEL 5
Volts/Ph
NORTEC
PART NO.
110-120 208/1 220-240/1 227/1 380/1 440-480/1 550-600/1 208/1 220-240/1 277/1 380/1 440-481/1 550-600/1 208/3 220-240/3 380/3 440-480/3 550-600/3 208/3 220-240/3 380/3 440-480/3 550-600/3
CONTACTOR 30 AMP 1PH
1453013 1 1 1 1 1 1 1 1 1 1
CONTACTOR 30 AMP 3PH
1323013 1 1 1 1 1 1 1 1
CONTACTOR 40 AMP 3PH
1323014 1 1 1 1 1
TERMINAL BLOCK 2 POLE
95A
1323001 1 1 1 1 1 1 1 1 1 1 1 1 1
TERMINAL BLOCK 3 POLE
95 AMP
1323027 1 1 1 1 1 1 1 1 1 1
3
GROUND CLAMP
1323020 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
TRANSFORMER 120/24
VAC 75 VA
1423110 1
TRANSFORMER 208 24V
75VA
1323208 1 1 1 1
TRANSFORMER 240/24
VAC 75 VA
1323230 1 1 1 1
TRANSFORMER 277/24V
75VA
1323277 1 1
TRANSFORMER 380/24V
75VA
1323380 1 1 1 1
TRANSFORMER 480/24
VAC 75 VA
1323460 1 1 1 1
TRANSFORMER 600/24
VAC 75 VA
1323575 1 1 1 1
PCB PROCESSOR NHPC
(NOT SHOWN)
2521274 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
PCB PROCESSOR NHTC
2521277 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
7
PCB DRIVER NHPC,
NHTC INCL. ELECTRICITY
CONVERTER
2521278 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
8
SWITCH, ROCKER, DPST
2522489 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
9
SWITCH SPST 208-240V
1473010 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
10
SWITCH INTERLOCK IDM
423
1323091 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
CABLE RIBBON 40 PIN
NHTC/NHPC
2522061 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
CABLE RIBBON 10 PIN
NHTC FAULT
2522062 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
CABLE EPROM SMALL
2522033 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1
2
4
6
SINGLE PHASE THREE PHASE
20 30
NOT SHOWN
10 20
ITEM
NO. DESCRIPTION
