Nortel DMS-100 Series Quick Reference Guide

vii
BMC II AMAT Quick Reference Guide
List of Tables
DMS-10 BMC AMAT software and firmware files 4
DMS-100 BMC AMAT software and firmware files 5
DCO BMC AMAT software and firmware files 6
Disk drive size and related number of tracks 10
Valid status values for CMD and STA bytes 17
Disk drive options 36
NT6M62xx CPU PCA 61
CPU LED display codes 61
NT6M63CA EPROM PCA 62
NT6M63CK, NT6M63DA, NT6M63DC, NT6M63FI, and
NT6M63FL EPROM PCA 63
NT6M60BA Quad SIO (Slot 6), BMC set to INTERNAL timing
and Polling Modem set to EXTERNAL timing 63
NT6M60BA Quad SIO (Slot 6), BMC set to EXTERNAL timing
and Polling Modem set to INTERNAL timing 64
NT6M60BA PTR SIO (Slot 7), BMC set to INTERNAL timing
and Polling Modem set to EXTERNAL timing 64
NT6M60BA PRT SIO (Slot 7), BMC set to EXTERNAL timing
and Polling Modem set to INTERNAL timing 65
Baud Rate Reference 65
NT6M84BA PWR/ALM Communications PCA, BMC set to
INTERNAL timing and Polling Modem set to EXTERNAL
timing 66
NT6M84BA PWR/ALM Communications PCA, BMC set to
EXTERNAL timing and Polling modem set to INTERNAL
timing 66
NT6M94xx 56K Interface PCA 67
NT6M66AC (MD) or NT6M66AH Disk Interface PCA 67
NT6M66BA SCSI Interface PCA 67
NT6M70AB DMS-100 DSI PCA 68
NT6M70BD DMS-100 DSI PCA 69
NT6M89AA DMS-10 TEC PCA 70
NT6M89AB and NT6M89BD DMS-10 TEC PCA 70
NT6M90xx 800 bpi DCO TEC PCA 71
NT6M90xx 1600 bpi DCO TEC PCA 72
