Component Identification
1. Handle: Designed for easy cart movement.
2. Pressure Hose: Attach quick couplers to gun and water outlet.
3. Chemical Hose: Submerge in cleaning solution.
4. Water Pump: Inspect for loose/broken parts prior to each use. A device that moves fluid through a
combination of suction and displacement.
5. Engine: Honda engine provides years of reliable use. Air cooled engine that powers the pump.
6. Nozzles: Change nozzles for different spray patterns.
7. Spray Gun: Always use two hands for safe operation.
8. Trigger: Actuate to allow pressurized water to flow out of spray gun.
9. High Pressure Outlet: Connect your high-pressure hose.
10. Garden Hose Inlet: Connect water supply for pump
11. Lifting Points: Lift the pressure washer from these points when transporting.
See “Parts Explosion” for more details
