North Star 1573021 - Specifications; Model Specifications; Wiring Diagram - Model 1573001

Specifications
20
1573001
1573011
PSI (bar)
1700 (117)
PSI (bar)
2000 (138)
GPM (l/min)
1.5 (5.7)
GPM (l/min)
1.5 (5.7)
Max Water Temp
140F (60C)
Max Water Temp
140F (60C)
Dimensions
L x W x H
34” x 21” x 38”
(864mm x 534mm x 965mm)
Dimensions
L x W x H
34” x 21” x 38”
(864mm x 534mm x 965mm)
Weight
95 lb (44kg)
Weight
115 lb (44kg)
1573021
PSI (bar)
2750 (190)
GPM (l/min)
2.5 (9.4)
Max Water Temp
140F (60C)
Dimensions
L x W x H
34” x 21” x 38”
(864mm x 534mm x 965mm)
Weight
139 lb (55kg)
Wiring Diagram
