Machine Component Identification
7
Ref Description Ref Description
1 2” Ball Coupler 11 Endplate
2 Horizontal Lock 12 Outrigger Legs
3 Lifting Handle 13 Engine
4 Cylinder 14 Hydraulic Tank
5 Hydraulic Oil Dipstick 15 Suction Strainer
6 Split Control Lever 17 Safety Chains
7 Control Valve 18 Vertical Lock
8 Wedge 19 Hydraulic Oil Filter
9 Log Cradle 20 Grease Zerks
10 Beam 21 Drain Plug
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
20
Fig 02407
21
