FIN INSTALLATION
1. Ensure the board, ns, grub screws and inlls are free from dirt and sand. Pay close attention
to the grub screw threads and n boxes.
2. Identify the correct orientation of each of the three ns.
3. Note: The symmetrically rounded n is the centre n. The two side ns have the at side
facing inwards.
4. Place the silicon inlls into the front of each of the n boxes. Insert each inll in at an angle,
engaging the front of each inll into the front of the box and then pushing the rear of each
inll down so it slides into the box.
5. Ensure you install the correct inll into the corresponding n box. The odd one out is the rear
n inll. The two asymmetrically angled inlls are the outer n box inlls and are labeled with
arrows pointing towards the rail.
6. Insert the three ns into their corresponding n boxes so the base of the n is ush with the
bottom of the board.
7. Tighten the two grub screws on both sides of each n box until rm, using the n key provid-
ed. Note: Do not over tighten as this may cause damage to the ns and boxes.
8. Ensure all three ns are secure and stable.
STRAP INSTALLATION
The North Comp Surfboard has been designed as a strapless board.
The North Charge and Cross Surfboard models are designed to be ridden with or without straps.
Please Note: Straps Sold Separately. The North Free Surf Straps can be purchased additionally. Visit
www.northkb.com to nd your local retailer.
Please refer to the Binding Manual for installation instructions online at northkb.com
LEASH INSTALLATION
All North Surfboards come attached with a leash attachment loop located on top of the board near
the tail.
To install a leash please refer to the leash manufacturers User Manual.
