Handle Bar
Ref.
Part No.
Description
Qty
Remark
C01
PL071-000B
Handle Bar Ass'y
1
C02
QNT-M16
Nut
2
M16 (10.9T)
C03
QWS-PM16
Plain Washer
2
M16 (10.9T)
C04
PL050-002
Handle Bar Bracket(R)
1
C05
QCWS-SM16
Conical Spring Washer
2
M16
C06
PL050-000
Handle Bar Bracket(L)
1
C07
QBL-M16X180H
Bolt
1
M16x180L
C08
QOS-45X32X8
Oil Seal
1
Ø45XØ32X8t
C09
PL080-005
Cylinder Head
1
C10
QOR-P40
O-Ring
1
P40
C11
PL080-006
Spacer
1
C12
QVP-45X32X3
V-Packing
3
Ø45XØ32X3.2t
C13
PG081-000
Cylinder Pipe Ass'y
1
C14
QWS-PM8
Plain Washer
3
M8 (10.9T)
C15
QWS-SM8
Spring Washer
3
M8 (10.9T)
C16
QBL-M8X25H
Bolt
3
M8x25L (10.9T)
C18
QFU-PT,PF 1/4
Hydraulic Nipple (Flare Union)
1
PT-PF 1/4, 5type
C19
QHH-450
Hydraulic Hose
1
450L
C20
QIF-PT1/4
Insert Fitting
1
PT1/4
C21
QPT-8X5X130
Polyurethane Tube
1
Ø8XØ5X130L
C22
QIF-PT1/4
Insert Fitting
1
PT1/4
C23
QSE-PT1/4
Service Elbow(90°)
1
PT1/4 90°
C24
QSR-S10
Snap Ring
1
S10
C25
PL080-001
Plunger
1
C26
PL080-008
Cylinder Pin
1
C27
PL080-002
Joint Plate
1
C28
QBL-M10X15
Bolt
1
M10X15L
C29
QWS-SM8
Spring Washer
1
M8 (10.9T)
C30
QBL-M8X25H
Bolt
1
M8x25L (10.9T)
C31
PG082-000
Handle Cam
1
C32
QNT-NM10
Lock Nut
1
M10
C33
PL080-003
Handle Bush
2
C34
PL080-004
Handle Shaft
1
C01
PL071-000
Handle Bar Ass'y
1
