NorthStar 49162 - Technical Specifications; Compactor and Engine Specs; Important Safety Information; General Safety Precautions

Page 5 of 28
Technical Specifications
Compactor
Weight
202.8 ~ 209.4 lbs. (92 ~ 95 Kg)
Centrifugal Force
4046 lbs. (1835 Kgf)
Vibration Frequency
100 Hz (6000 VPM)
Travel Speed (depending on soil)
82 ft./min (25 m/min)
Grade Ability
20%
Compacted Area (depending on soil)
6781.2 ft
2
/hr (630 m
2
/hr)
Power Take-Off
Centrifugal Clutch & V-Belt
Engine
Engine Maker
HONDA
Engine Model
GX 160 / 163cc
Output Power(max)
5.5 Hp. (4.0 Kw)
Spark Plug
BPR6ES(NGK)
W20EPR-U(DENSO)
Spark Plug Gap
0.028-0.031 in. (0.7-0.8 mm)
Engine Speed - Full Load
3,600±100 RPM
Engine Speed - Idle
1,400±100 RPM
Air Cleaner Type
Dual Element
Engine Oil Type
SAE 10W-30
Engine Oil Capacity
20 oz. (600 ml)
Fuel Type
Unleaded Gasoline
Fuel Tank Capacity
3.8 qt. (3.6 l)
Important Safety Information
 The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
 DO NOT allow persons to assemble or operate this product until they have read this manual and
have developed a thorough understanding of how the product works.
 Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. It will
do the job better and more safely at the capacity for which it was intended. DO NOT use this
equipment for a purpose for which it was not intended.
 Industrial or commercial applications must follow OSHA requirements.
