MACHINE COMPONENT IDENTIFICATION
Figure 1 (Ref. 1-9)
2275
Ref. Description Ref. Description
1 Generator 9 Air Cleaner Housing
2 Grounding Screw 10 Recoil Handle
3 Control Panel 11 Muffler
4 Isolation Mounts 12 Battery Box
5 Oil Drain Plug 13 Warning Decals
6 Oil Filter Access Cover 14 6.5 Gallon Fuel Tank
7 Oil Fill and Dip Stick 15 Fuel Cap with Gauge
8 Operation Instructions
