NorthStar e300 - Page 25

Item 114593 (804313) - e300 Engine Parts Explosion– Rev A.4
25
REF#
PART #
DESCRIPTION
QTY
1
Kit #8
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
4
2
Kit #8
COVER SUBASSEMBLY, CYLINDER HEAD
1
3
Kit #4, Kit #8
CYLINDER HEAD COVER GASKET
1
4
Kit #4, Kit #8
GASKET, BREATH GROOVE
1
5
Kit #8
STOP ENGINE PIECE SUBASSEMBLY
1
6
Kit #7
SHAFT SUBASSEMBLY， ROCKER
2
7
Kit #7
ROCKER SUBASSEMBLY, VALVE
2
8
Kit #7
CYLINDER HEAD COVER PIN LIMIT PLATE
1
9
Kit #7
ROTATOR, VALVE
2
10
Kit #7
CLAMP, VALVE LOCK
4
11
Kit #7
SEAT, VALVE SPRING
2
12
Kit #7
SPRING, VALVE
2
13
Kit #7
GUIDE, SEAL
1
14
Kit #7
VALVES SET
1
15
Kit #9
CYLINDER HEAD BOLT
4
16
Kit #9
HEAD SUBASSEMBLY, CYLINDER
1
17
Kit #4, Kit #9
GASKET, CYLINDER HEAD
1
18
Kit #9
POSITION PIN - TYPE A
2
19
N/A
RING ASSY, PISTON
1
20
N/A
CLIP, PISTON PIN
2
21
N/A
PIN, PISTON
1
22
N/A
PISTON
1
23
N/A
ROD, CONNECTING
1
24
Kit #9, Kit #10
PLUG, SPARK
1
25
Kit #9
STUD BOLT (BM=2D)
2
26
Kit #2, Kit #4,
GASKET, EXHAUST OUTLET
1
27
Kit #6, Kit #7, Kit #8,
Kit #20, Kit #23
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
11
28
Kit #2
MUFFLER
1
29
Kit #2
LOCK NUT
5
30
Kit #9
STUD BOLT (BM=2D)
2
31
Kit #4, Kit #5
GASKET, INLET
1
32
Kit #5
PLATE, CARBURETOR INSULATOR
1
33
Kit #4, Kit #5
CARBURETOR SEAL GASKET
1
34
805464
ECU ASSEMBLY
1
35
Kit #4, Kit #5
AIR CLEANER SEAL GASKET
1
36
Kit # 1
KNOB
1
37
Kit #1
HEXAGON NUT WITH FLANGE
2
38
Kit #9
SHROUD, CYLINDER BODY
1
39
805750 or Kit #9
SENSOR, TEMPERATURE
1
40
Kit #1
PIPE CLAMP
2
41
Kit #1
TUBE, BREATHER
1
42
Kit #1
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
1
43
Kit #2
PIPE, EXHAUST
1
44
N/A
CRANKSHAFT ASSY.
1
45
Kit #2, Kit #4
GASKET, MUFFLER
1
46
Kit #4, Kit #21
GASKET, CRANKCASE
1
47
Kit #21
POSITION PIN - TYPE A
2
