NorthStar e300 - Specifications

Specifications
5
114593 (804313) – e300
114594 (804314) – e420
DIMENSIONS/COMPONENTS
DIMENSIONS/COMPONENTS
Engine Type
Four- stroke, Overhead, Single-
Cylinder
Engine Type
Four- stroke, Overhead, Single-
Cylinder
Length
18.90in
Length
20.28in
Width
13.00in
Width
14.57in
Height
17.91in
Height
18.31in
Net Weight
62.8lbs
Net Weight
76lbs
Displacement
301cc
Displacement
420 cc
Fuel Tank Capacity
1.45 Gal (5.5L)
Fuel Tank Capacity
1.64 Gal (6.2L)
Compression Ratio
8.2:1
Compression Ratio
8.2:1
Cylinder Diameter X
Stroke
3.15X2.36in
Cylinder diameter X
Stroke
3.54X2.60in
Maximum Output
Power
6.2 kW / 3600 rpm
Maximum Output
Power
8.8 kW / 3600 rpm
Net Torque
13.28ft-lbs. / 2500 rpm
Net Torque
18.44 ft-lbs. / 2500 rpm
Cooling System
Forced Air Cooling
Cooling System
Forced Air Cooling
Ignition System
Transistorized Coil Ignition (TCI)
Ignition System
Transistorized Coil Ignition (TCI)
Spark Plug
F6RTC / F7RTC
Spark Plug
F6RTC / F7RTC
Lubrication System
Splash Type
Lubrication System
Splash Type
Oil Capacity
1.06 qt. (33.81 oz.)
Oil Capacity
1.17 qt. (37.19 oz.)
Power Output Shaft
Direction
Counterclockwise
Power Output Shaft
Direction
Counterclockwise
Output Shaft
1in x 3.48in Length with 1/4in
keyway
Output Shaft
1in x 3.48in Length with 1/4in
keyway
Mounting Face
SAE J609 Flange B
5/16-24 UNF 2B Tap on a
5.00in(126.5mm) bolt circle
and 3/8-16 UNC 2B Tap on a
6.50in (165.1mm) bolt circle
Mounting Face
SAE J609 Flange B
5/16-24 UNF 2B Tap on a
5.00in(126.5mm) bolt circle
and 3/8-16 UNC 2B Tap on a
6.50in (165.1mm) bolt circle
Clearance of spark
plug
0.028 – 0.031in
Clearance of spark
plug
0.028 – 0.031in
Valve clearance
0.002 – 0.0039in
Valve clearance
0.002 – 0.0039in
Operating
Temperature (ºF)
14ºF to 104ºF
Operating
Temperature (ºF)
14ºF to 104ºF
