Specifications
6
114656 (804315) – e420 (Electric Start)
DIMENSIONS/COMPONENTS
Engine Type
Four- stroke, Overhead, Single-
Cylinder
Length
19.5in
Width
14.57in
Height
18.31in
Net Weight
80.5lbs
Displacement
420 cc
Fuel Tank Capacity
1.64 Gal (6.2L)
Compression Ratio
8.2:1
Cylinder diameter X
Stroke
3.54X2.60in
Maximum Output
Power
8.8 kW / 3600 rpm
Net Torque
18.44 ft-lbs. / 2500 rpm
Battery Requirement
12 VDC – 14 Ahr
*Battery required for operation
Cooling System
Forced Air Cooling
Ignition System
Transistorized Coil Ignition (TCI)
Spark Plug
F6RTC / F7RTC
Lubrication System
Splash Type
Oil Capacity
1.17 qt. (37.19 oz.)
Power Output Shaft
Direction
Counterclockwise
Output Shaft
1in x 3.48in Length with 1/4in
keyway
Mounting Face
SAE J609 Flange B
5/16-24 UNF 2B Tap on a
5.00in(126.5mm) bolt circle
and 3/8-16 UNC 2B Tap on a
6.50in (165.1mm) bolt circle
Clearance of spark
plug
0.028 – 0.031in
Valve clearance
0.002 – 0.0039in
Operating
Temperature (ºF)
14ºF to 104ºF
