NorthStar e300 - Page 27

Item 114593 (804313) - e300 Engine Parts Explosion– Rev A.4
27
97
Kit #17, Kit #19
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
98
Kit #15
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
99
N/A
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
100
Kit #12, Kit #19
CABLE TIE
3
101
Kit #1, Kit #10
AIR CLEANER ELEMENT ASSEMBLY
1
102
Kit #3
COLLECTOR, SPARK
1
103
Kit #3
CROSS-RECESSED SELF-TAPPING SCREW
4
104
Kit #1
COVER, AIR CLEANER CASE
1
105
Kit #1
BUTTERFLY NUT - STAMPED
1
106
Kit #1
ELBOW SUBASSEMBLY, AIR CLEANER
1
107
Kit #6
HEXAGON SOCKET FLANGE FACE BOLT
3
108
Kit #6
SHROUD
1
109
Kit #6, Kit #19
CABLE TIE
2
110
Kit #15
WIRE CLIP
1
111
Kit #1
FILTER ELEMENT SUPPORT PLATE
1
112
Kit #1, Kit #4
AIR FILTER HOUSING GASKET
1
113
Kit #13
FLAT WASHER
4
114
Kit #19
CASE, BATTERY
1
115
Kit #19
BOLT
2
116
805943
ECU WIRING HARNESS - BATTERY
1
117
N/A
CABLE TIE
1
