Item 114594 (804314) – e420 Engine Parts Explosion – Rev A.4
32
48
Kit #1
COVER, AIR CLEANER CASE
1
49
Kit #1
BUTTERFLY NUT - STAMPED
1
50
Kit #1, Kit #10
AIR CLEANER ELEMENT ASSEMBLY
1
51
Kit #1
AIR CLEANER BASE BODY
1
52
Kit #1
HEXAGON NUT WITH FLANGE
2
53
805577
CRANKCASE SUBASSEMBLY.
1
54
Kit #24
FLAT WASHER
2
55
Kit #24
BOLT, DRAIN PLUG
2
56
Kit #20
CONTROL ASSY BASE PLATE, THROTTLE
1
57
Kit #11, Kit #25
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
4
58
805578
SEAL, OIL
1
59
N/A
PLUG, RUBBER
1
60
Kit #23
COIL SUBASSEMBLY, CHARGE
1
61
Kit #23
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
2
62
Kit #23
CLAMP, CHARGE COIL
1
63
Kit #23
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
1
64
Kit #25
TRIGGER ASSY.
1
65
805490
FLYWHEEL SUBASSEMBLY
1
66
Kit #22
IMPELLER
1
67
Kit #22
PULLEY, STARTER
1
68
Kit #22
NUT, FLYWHEEL
1
69
Kit #5
HIGH PRESSURE FUEL TUBE SUBASSEMBLY
1
70
805491
ECU WIRING HARNESS
1
71
Kit #6, Kit #19
WIRE CLIP
3
72
Kit #6
STARTER ASSY, RECOIL
1
73
Kit #6
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
3
74
805571
LED LOGO
1
75
805579
CRANKSHAFT ASSY.
1
76
805580
DEEP GROOVE BALL BEARING - P53
2
77
805581
SHAFT ASSY, BALANCING
1
78
Kit #7
CAMSHAFT ASSY.
1
79
Kit #7
TAPPET, VALVE
2
80
Kit #7
LIFTER SUBASSEMBLY, VALVE
2
81
Kit #11
HEXAGON NUT WITH FLANGE
1
82
Kit #11
SENSOR, ENGINE OIL
1
83
Kit #4, Kit #21
GASKET, CRANKCASE
1
84
Kit #21
POSITION PIN - TYPE A
2
85
Kit #21
DEEP GROOVE BALL BEARING - P53
1
86
Kit #21
COVER, CRANKCASE
1
87
805467 or Kit #21
DIPSTICK SUBASSEMBLY, OIL
2
88
Kit #21
SEAL, OIL
1
89
Kit #21
HEXAGON SOCKET FLANGE FACE BOLT - SMALL SERIES
7
90
Kit #19
MOUNTING BRACKET
1
91
Kit #2, Kit #19
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
5
92
Kit #19
REGULATOR, VOLTAGE
1
93
805582 or Kit #12
COIL, IGNITION
1
94
Kit #12
HEXAGON SOCKET FLANGE FACE BOLT - BIG SERIES - GRADE B
2
95
805762
WIRE CLIP
1
96
Kit #6, Kit #19
BAND
3
